The Piper PA-18 Super Cub is a two-seat, single-engine monoplane. It was developed from the Piper PA-11. In close to 40 years of production, over 9,000 were built. Super Cubs are commonly found in roles such as bush flying, banner towing and glider towing. As a relative of the popular 1400mm J-3 Cub, the 1700mm PA-18 Super Cub retains great flight characteristics while offering increased power and wingspan. Thanks to its functional flaps, high-lift airfoil, rugged landing gear and oversized balloon tires- the 1700mm PA-18 Super Cub has impressive short take-off and landing (STOL) performance, allowing it to operate from just about any terrain. Utilizing the latest FMS hardware and design, the 1700mm PA-18 Super Cub has pre-installed ball-link type pushrods, integrated servo connectors in the wing structure and can be assembled very easily using no glue at all.
For pilots wanting to get the genuine bush-plane experience, the PA-18 Super Cub can be equipped with floats.
Versatile, fun and exceptionally relaxing to fly- the 1700mm PA-18 Super Cub is a great addition to any fleet!
Features: 1. Powerful 3541- 750KV Outrunner motor with Predator 45A ESC provides adequate thrust for any situation. 2. CNC metal landing gear structure for less-than-perfect landings. 3. 6.25-inch oversized balloon tires for all-terrain operations. 4. STOL capable (Takes off in less than 3m/10ft) 5. Pre-installed navigation and landing lights 6.Two-piece wing and horizontal stabilizer for easy transportation 7. High-strength carbon fiber wing spars 8.Integrated servo connectors 9. Screw-together assembly 10.Large battery bay 11.Ball-linked pushrods for increased precision 12.Tough two bladed Nylon propellers 13. Functional flaps 14. Optional floats and stainless-steel wing struts
Notes to buyers:
RTF (Ready to Fly) airplanes come with everything you need to fly in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory. PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
Specification |
Wingspan |
1700MM/66.9in |
Overall length |
1136MM/44.7in |
Flying weight |
2100g |
Motor size |
3541-KV750 |
ESC |
45A |
Servo |
17g*6 |
Radio |
6 Channel |
CG (center of gravity) |
80-85mm(From leading edge) |
Prop Size |
12*7.5, 2-blade |
Recommended battery |
14.8V 2200-2600mAh 4s 35C |
Battery Connector |
XT60 |
Aileron |
Yes |
Elevator |
Yes |
Rudder |
Yes |
Flaps |
Yes |
Retracts |
No |
LED |
Yes |
Approx. flying duration |
4-5 minutes |
Minimum age recommendation |
14+ |
Experience level |
intermediate |
Assembly time |
around 40 minutes |
Wing load |
50g/dm²; 0.11oz/in2 |
Wing area |
42dm² ;651sq.in |
|
