FMS EDF Jet 80mm Futura V3 PNP
Description
The pinnacle of what a foam jet can be - Futura V3
The FMS Futura is a licensed sport jet developed by FMS in conjunction with Tomahawk- Aviation. Designed by a Sino-German team of engineers, the Futura represents the pinnacle of what a foam jet can be.
While retaining V1 features such as the CNC metal trailing-link landing gear for rough field operations, robust airframe with high-strength wing spars, oversized electronics bay, etc, and V2 features such as 13g all-metal digital servos for increased precision and torque, improved durable and reliable plug-type connectors, the FMS 80mm Futura V3 is upgraded with added alternately flashing navigation lights on the left and right wings and taxi lights on the bottom of the fuselage, and a recognizable and attractive red-grey paint scheme.
Powering the Futura V3 is an industry-leading Hobbywing 100A ESC paired with an uprated 3665-KV2000 motor turning an 80mm 12-bladed fan- delivering breathtaking power with absolute confidence.
Features
1. Power system: Hobbywing 100A ESC, 3665-KV2000motor, 80mm 12 bladed fan
2. CNC all-metal landing gear. 10mm diameter worm drive, trailing-link suspension, highly precise and robust.
3. All servos upgraded to 13g digital all-metal units for improved precision and torque
4. Large tires- suitable for rough-field operations
5. Oversized electronics bay for easy maintenance and accepts large capacity batteries
6. Glue-less assembly, the aircraft is built with only 10 screws
7. Environmentally friendly water-based paint
8. Buckle design latch prevents unexpected canopy release in flight
9. Improved plug-type connectors for added durability and reliability
10. Added alternately flashing navigation lights on wings and taxi lights on the bottom of the fuselage for reproduction and fun to the flight
11. Recognizable and attractive red-gray paint scheme
What's in Box
(1) 80mm EDF with 12 bladed fan
(2) 3665-KV2000 Brushless Motor (installed)
(3) Hobbywing 100A ESC ESC (installed)
(4) 13g Digital All-metal Servos (installed)
(5) CNC All-metal Landing Gear (installed)
(6) Flashing Navigation Lights On Wings And Taxi Tights On the Bottom Of the Fuselage (installed)
(7) Attractive Red-gray Decal
(8) Product Manual
Specification | |
Wingspan | 1060mm/41.7in |
Overall Length | 1170mm/46.1in |
Flying Weight | Around 2500g |
Motor Size | 3665-KV2000 |
ESC | 100A |
Servo | 13g metal analog Servo x 8 |
Radio | 6 Channel |
CG (center of gravity) | 100-105mm (From Leading Edge) |
EDF | 80mm Ducted Fan 12-blade |
Recommended Battery | Li-Po 22.2V 4000mAh 35C |
Battery Connector | EC5 |
Aileron | Yes |
Elevator | Yes |
Rudder | Yes |
Flaps | Yes |
Retracts | Yes |
Approx. Flying Duration | 3-5 minutes |
Minimum Age Recommendation | 14+ |
Experience Level | Intermediate |
Assembly Time | 15 minutes |
Wing Load | 113.6g/dm² (0.26oz/in²) |
Wing Area | 22dm² (341sq.in) |
Notes to buyers:
RTF (Ready to Fly) airplanes come with everything you need to fly in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory.
PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
FMS EDF Jet 80mm F-86 Sabre PNP
Description
Wingspan | 1220mm /48 in |
Overall Length | 1165mm /46 in |
Flying Weight | Around 3050g |
Motor Size | 3665-KV2000 |
ESC | 100A |
Servo | 13gX8, 9gX3 |
Radio | 6 Channel |
CG (center of gravity) | 180-190mm |
Prop Size | 80mm Ducted Fan 12-blade |
Recommended Battery | 22.2V 4000mAh-5500mAh 45c |
Battery Connector | EC5 |
Battery Compartment Size | 200*68*45mm |
Aileron | Yes |
Rudder | Yes |
Flaps | Yes |
Retracts | Yes |
Approx. Flying Duration | 3 minutes |
Minimum Age Recommendation | 14+ |
Experience Level | Upper-Intermediate |
Assembly Time | 10 minutes |
Wing Load | 95.3 g/dm² (0.18oz/in²) |
Wing Area | 32dm² (495.8 sq.in) |
FMS EDF Jet 80mm Rafale PNP
Description
Innovative Design, 80MM Rafale RC EDF Jet
FMS 80mm Rafale features an attractive trim scheme, excellent scale details and fully functional canards- allowing the aircraft to be truly unique when compared to other 80mm EDF aircraft. Details such as the pilot, cockpit interior, panels, removable armaments, auxiliary fuel tanks, refueling probe, targeting sensor etc; dynamic features such as functional LED navigation and landing lights, CNC shock-absorbing electric retracts, functional canards and flaps etc.
Utilising screws, latches and quick connectors, experienced builders can complete the build process in as little as 5 minutes.
Functions such as delta-mixing, sequential landing gear bay doors, alternating flash navigation lights, nose gear landing lights, slowed flaps etc are all controlled by a central control board. An 80mm 12 bladed EDF with a platinum edition 3280 inrunner motor and 100A high performance ESC easily accomplishes fighter jets maneuvers with realistic sound and speed.
Highlights
- 3280-2100KV platinum edition inrunner motor with a high-performance 100A ESC
- Delta wing design with full flying canards and functional flaps
- CNC metal shock-absorbing landing gear
- Functional navigation and landing lights
- Central function controller
- Functional and static details lovingly replicated
- Water based vibrant trim scheme
What's in Box
- 80mm EDF with 12 bladed fan
- 3280-2100KV Brushless Motor (installed)
- Hobbywing 100A ESC (installed)
- 13g Digital All-metal Servos (installed)
- CNC All-metal Landing Gear (installed)
- Flashing Navigation Lights On Wings And Taxi Tights On the Bottom Of the Fuselage (installed)
- Attractive Red-gray Decal
- Product Manual
Need to Complete
Transmitter
6+ channel Receiver
22.2V4000mAh-5000mAh 45c (recmmanded)
Compatible Charger
Notes to buyers:
RTF airplane comes with everything necessary for flight in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory.
PNP airplane comes pre-installed with ESC, motor, and servos. The Transmitter, Receiver, Battery, and Charger are NOT included.
Specification
Specification | |
Wingspan | 974mm /38.3 in |
Overall Length | 1409mm /55.5 in |
Flying Weight | Around 3280g |
Motor Size | 3280 KV2100 |
ESC | 100A |
Servo | 13gX7pcs |
Radio | 6CH Channel |
CG (center of gravity) | 110-130mm |
Prop Size | 12叶 |
Recommended Battery | 22.2V4000mAh-5000mAh 45c |
Battery Connector | EC5 |
Aileron | Yes |
Rudder | Yes |
Flaps | Yes |
Retracts | Yes |
Approx. Flying Duration | 3minutes |
Minimum Age Recommendation | 14+ |
Experience Level | |
Assembly Time | 5minutes |
Wing Load | 85.2 g/dm² ( 0.17oz/in²) |
Wing Area | 38.5 dm² ( 596.6 sq.in) |
