FMS EDF Jet 90mm Super Scorpion V2 PNP
Description
Fly Fast, at the Cutting Edge of RC EDF Jet Aviation
The all-new FMS 90mm EDF Super Scorpion V2 is here. Designed to elevate your flight experience with its upgraded inrunner motor and unique 12-blade fan. You'll feel the power and hear the difference! Choose between striking orange or camouflage paint schemes, both optimized for increased visibility and realism in flight. Available in 6S and 8S versions, this advanced sport jet delivers on every front; speed, stability, and maneuverability. Ready to dominate the skies? The Super Scorpion V2 has arrived!
Features
1. New! Improved CNC machined trailing link struts, ensuring smooth suspension and effectively reducing the impact force to the airframe during takeoff, landing, and taxiing.
2. New! Available in both 6S (3670-KV1950 inrunner motor) and 8S (4075-KV1500 inrunner motor) versions.
3. New! Available in two different paint schemes; orange and camouflage!
4. Electric retracts with locked-rotor mode and over-current protection.
5. Multi-plug connectors for added durability, reliability, and ease of assembly.
6. Preinstalled ball link connector for increased throw and precision.
7. Screw-together assembly.
8. High-quality wear-resistant tires.
9. Buckle-design latch prevents unexpected canopy release in flight.
10. Flap functionality to help ease takeoff and landing.
11. Environmentally friendly water-based paint for better color and adhesion.
12. High quality EPO foam.
In The Box
(1) 90mm Super Scorpion V2 EDF PNP
(2) 120A ESC with Reverse Thrust Function (installed)
(3) 6S (3670-KV1950 inrunner motor) or 8S (4075-KV1500 inrunner motor) options (installed)
(4) 90mm 12-blade ducted fan (installed)
(5) 9 High-precision All-metal Digital Servos (installed)
(6) Product Manual
Needed to Complete
(1) 6 Channel Transmitter and Receiver
(2) 6S (22.2V 5000mAh-6000mAh 45c with EC5 connector) / 8S (29.6V 5000mAh-5500mAh 45c with EC5 connector)
(3) LiPo Battery Charger
Notes to Buyers
① RTF (Ready to Fly) airplanes come with everything you need to fly in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory.
② PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
③ EPO foam and cockpits can bubble or deform in high heat. To prevent this, avoid leaving them in direct sunlight when not in use.
④ Reflex V3 is not included and needs to be purchased separately.
⑤ 6-channel receiver is needed for Ailerons, Elevator, Throttle, Rudder, Landing Gear, and Flaps. Upgrade to 7 or more channels for advanced features like Thrust Reverse and Reflex Control.
Specification
Model | 6S | 8S |
Wingspan | 1140mm /44.9 in | 1140mm /44.9 in |
Overall Length | 1320mm /52in | 1320mm /52in |
Flying Weight | Around 3500g | Around 3950g |
Motor Size | 3670-KV1950 | 4075-KV1500 |
ESC | 120A | 120A |
Servo | 13gX5pcs | 13gX5pcs |
Servo | 23gX4pcs | 23gX4pcs |
Radio | 6CH Channel | 6CH Channel |
CG (center of gravity) | 150-160mm | 150-160mm |
Prop Size | 90mm 12-blade ducted fan | 90mm 12-blade ducted fan |
Recommended Battery | 22.2V 5000mAh-6000mAh 45c with EC5 connector | 29.6V 5000mAh-5500mAh 45c with EC5 connector |
Aileron | Yes | Yes |
Rudder | Yes | Yes |
Flaps | Yes | Yes |
Retracts | Yes | Yes |
Approx. Flying Duration | 3 minutes | 3 minutes |
Minimum Age Recommendation | 14+ | 14+ |
Experience Level | Intermediate | Intermediate |
Assembly Time | 10 minutes | 10 minutes |
Wing Load | 119 g/dm² (0.23oz/in²) | 134.3 g/dm² (0.26oz/in²) |
Wing Area | 29.4dm² (455.5 sq.in) | 29.4dm² (455.5 sq.in) |
FMS EDF Jet 90mm Avanti PNP 18th Anniversary Edition
Description
Wingspan | 1290mm /50.8 in |
Overall Length | 1360mm /53.5 in |
Flying Weight | Around 3200g |
Motor Size | 3670 KV1950 |
ESC | 120A |
Servo | 13gX8pcs |
Radio | 6CH Channel |
CG (center of gravity) | 125-135mm |
Prop Size | 90mm Ducted Fan 12-blade |
Recommended Battery | 22.2V 5000mAh-6000mAh 45c with EC5 connector |
Aileron | Yes |
Rudder | Yes |
Flaps | Yes |
Retracts | Yes |
Approx. Flying Duration | 3 minutes |
Minimum Age Recommendation | 14+ |
Experience Level |
Intermediate/Advanced
|
Assembly Time | 10 minutes |
Wing Load | 100 g/dm² (0.19oz/in²) |
Wing Area | 32dm² (495.8 sq.in) |
FMS 1700mm F7F Tigercat Blue PNP
Description
After almost two years development, numerous tests and improvements, we have reproduced the classical highly anticipated F7F! FMS 1700mm Tiger Cat is coming!
The FMS 1700mm Tiger Cat pools the best structural features from FMS’ classic works. It adopts the popular quick and easy assembly and disassembly structure. Screws can do all assembly and disassembly work. In addition, with the latest multi-connect technology, FMS has streamlined the wing system, eliminating the wiring problems, and making it easier to install and dismantle in a short time. The well-designed battery compartment makes full use of airframe space, allowing for higher-storage batteries and more flying choices.
FMS’ warbirds are always attractive, no matter from the perspective of scaled appearance, or from excellent performance. This also applies to the Tiger Cat.
The Tiger Cat features the latest locked-rotor mode E-retract system with overcurrent protection, the refined scaled CNC-processed metal landing gear set (Certainly the most notable feature is that this is the most accurately scaled landing gear set we have ever created) for resisting those not-too-perfect landings, a 62mm diameter front wheel and 84mm diameter rear wheels for taking off and landing on both paved and grass surfaces. The power system utilizes twin 4258-KV460 outrunner motors, twin 60A ESC (with 10A UBEC), providing surging power for scaled aerial combat maneuvers when coupled with a 6S 5000mAh 45C battery.
The Tiger Cat has the most scaled appearance, with scaled plastic parts throughout the body, e.g. landing gear door, cowl, artificial engine, and machine guns... Couple that with the detailed all-around rivets, panel lines, pilot figure, high bright LED lamps, a CNC-processed shock-absorbed metal landing gear set, the Tiger Cat is reproduced flawlessly. Moreover, 4 set decals in the package (blue color scheme only) allow you to make your own Tiger Cat and stand out in your airfield
It is more than an RC model. It is one for the collectors. Go get the FMS 1700MM “Tiger Cat” to experience its magnificence.
Key Features:
1.Powerful twin 4258-KV460 motors with twin Predator 60A ESC (with 10A UBEC)
2.The most accurately scaled landing gear set we have ever created
3.Super high-scale detail throughout:
- Scaled CNC-processed metal landing gear set
- Pilot figure
- Panel lines and all-around rivets…
- high-brightness LED set
4.The latest locked-rotor mode E-retract with overcurrent protection
5.Metal digital servos for excellent controlling capacity
6.Multi-connector for one-step installation
7.Screw-together construction
8.A 62mm diameter front wheel and 84mm diameter rear wheels for taking off and landing on both paved and grass surfaces.
9.Large bearings in wheel hub for better performance
10.Button Type canopy hatch
11.Large battery compartment
12.Four set decals for DIY (blue color scheme only), to be different.
Notes to buyers:
RTF (Ready to Fly) airplanes come with everything you need to fly in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory.
PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
Specification
|
|
Wingspan | 1700mm/ 66.9in |
Overall Length | 1,484mm/ 58.4in |
Flying Weight | 5200g |
Motor Size | Brushless Motor 4258-KV460 x 2 |
ESC | 60A x 2 With 10A UBEC |
Servo | 7 x 13g metal analog, 5 x 17g metal digital |
Radio | 6 Channel |
CG (center of gravity) | 70-80mm (From leading edge) |
Prop Size | 14*8, 3 blades propeller |
Recommended Battery | Li-Po 22.2V 5000mAh 45C |
Battery Connector | EC5 |
Aileron | Yes |
Elevator | Yes |
Rudder | Yes |
Flaps | Yes |
Retracts | Yes |
Approx. Flying Duration | 5 minutes |
Minimum Age Recommendation | 14+ |
Experience Level | Intermediate |
Assembly Time | 30-60 minutes |
Wing Area | 49.1d㎡/ 761sq.in |
FMS 1700mm F4U Corsair V3 PNP
Description
The FMS Corsair airframe features a removable 2 piece wing that is simplistic in attachment and connection, the new FMS® multi-pin plugs mean that the complex wiring is now just a single connection per wing and not the usual plate full of spaghetti normally seen in lesser airframes.
The large cockpit is adorned with the full complement of dials and levers and the hand painted pilot finishes the effect. The chrome spinner and reinforced nylon four blade propeller really does give a purposeful look and assist in giving rise to the knick name of the whistling death.
As you would expect, the huge brushless out- runner motor is mated with a top quality ESC enabling stunning flight performance.
New metal gear servos handle all the control surfaces and are fast with great centering performance. The resulting flight performance gives a finesse unseen in a model in this class. Order the 1700 Series F4U Corsair today and steal the limelight at your airfield.
More info, please visit RCgroups:
http://www.rcgroups.com/forums/showthread.php?t=1512298
Features
• Upgraded 5060 brushless motor with high-performance Hobbywing 80A ESC
• Upgraded 18x11 four-bladed scale propeller
• Upgraded CNC metal, electric, shock-absorbing retracts
• Removable vertical stabilizer for easy transportation
• Upgraded large battery compartment with a latch-type canopy
• Improved hinge design
• Extremely detailed airframe
• Bearing-equipped durable wheels
• Screw-together assembly with plug connectors
• Preinstalled ball-link pushrods
Highlight
The inverted gull-wings of the Vought F4U Corsair is one of the most identifiable icons of the Second world war and Korean war. Known for its blistering speeds, high climb rate, survivability and firepower, the Corsair achieved an amazing 11:1 kill:loss ratio against Japanese fighters in the Pacific theater.
FMS is proud to introduce the all-new 1700mm F4U V3. Powered by a 6S power system, Hobbywing 80A ESC, 5060 motor and a 11x18 four bladed prop, the F4U V3 has an extremely wide flight-envelope: adrenaline-pumping speeds and deceivingly trainer-like slow speed performance; making the Corsair one of the easiest flying warbirds on the market today.
Committed to creating the most visually realistic aircraft on the market, FMS has added numerous scale features onto the 1700mm F4U V3. Pitot tubes, missile racks, auxiliary fuel tank, aerials, exhausts, realistic tail gear, pilot figure etc. allow the aircraft to look statically realistic. Rotating electric retracts, 3 position flaps, navigation and landing lights, slow retracting gear bay doors add to the dynamic realism of the aircraft.
Operating out of an unpaved airstrip? The shock-absorbing metal retracts with bearing-equipped wheels not only look great, they greatly reduce airframe stress during ground operations. The screw-together assembly and plug type wing connectors make the assembly process a breeze.
Turn heads at the field with the 1700mm F4U V3- a must have for every warbird fan.
Notes to buyers:
RTF (Ready to Fly) airplanes come with everything you need to fly in the box. A transmitter, receiver, battery, charger, and all other required electronics are included and pre-installed from the factory.
PNP (Plug-and-Play) airplanes include the ESC, motor, and servos all pre-installed from the factory. Transmitter, receiver, battery, and charger are not included.
Specification | |
Wingspan | 1700mm/66.9in |
Overall Length | 1,360mm/53.5in |
Flying Weight | Around 5,300g |
Motor Size | Brushless 5060-KV300 |
ESC | 80A |
Servo | 2 x 9g analog, 2 x 17g metal digital, 8 x 17g plastic digital |
Radio | 6 Channel |
CG (center of gravity) | 115-125mm (From Leading Edge) |
Prop Size | 18*11 |
Recommended Battery | Li-Po 22.2V 5000-6000mAh 45C |
Battery Connector | EC5 |
Aileron | Yes |
Elevator | Yes |
Rudder | Yes |
Flaps | Yes |
Retracts | Yes |
Approx. Flying Duration | 6 minutes |
Minimum Age Recommendation | 14+ |
Experience Level | Intermediate |
Assembly Time | 20 mins |
Wing Load | 97.8g/d㎡ |
Wing Area | 54.2d㎡ |
